Vertical waste baler HSM V-Press 610 Eco, 12 tonne, 120 kN, 100 kg bales

Waste baler HSM V-Press 610 eco

The HSM V-Press 610 automatic baling press is perfectly suited for compacting packaging materials such as film, cardboard, or paper into bales. This baler is most effective when positioned at the point where waste is generated. Manage your packaging waste efficiently and cost-effectively.

• Pressing force: 12 tonnes or 120 kN
• Bale mass: up to 100 kg (material dependent)
• Bale dimensions: L 800 × W 600 × H max. 600 mm
• Manufactured in Germany – Premium quality
• Delivered to your address (DAP) · export price without VAT; export customs clearance at a fixed fee; import VAT and duties are paid by the buyer
• Ready to use – straightforward installation and operation
• Dimensions: 1198 x 823 x 1986 mm (Width x Depth x Height)
• Machine mass: 540 kg
• Filling aperture: W 800 x D 495 mm
• Press chamber size: W 800 x D 600 x H 1045 mm
• Motor output: 3 kW
• Power supply / frequency: 3 x 400 V / 50 Hz
• Sound level during operation: 80 dB

With the HSM V-Press 610 automatic baling press, you can compact used packaging materials such as film, cardboard, or wrapping paper into solid bales for recycling. Thanks to its compact footprint of only 2–3 m², the baler can be installed directly at the source of the waste, reducing internal transport distances and improving on-site logistics for packaging material removal.
To operate, simply load the packaging material into the upper section of the machine. A safety switch ensures the press cycle begins automatically once the door is closed, and stops immediately if the door is opened during operation. The robust press plate compacts the loaded material into bales weighing up to 100 kg, using stable press plate guides and a pressing force of 120 kN. The integrated TorsionControlSystem (TCS) continuously monitors the press plate’s alignment in all directions, preventing uneven loading and ensuring optimal compaction. The HSM V-Press 610 can process packaging material into 3–6 bales per hour. Each bale is automatically secured with a strap. The bale can then be easily removed using the mechanical bale ejector and transported away with a pallet truck. Compacted bales are less flammable, reducing fire risk, and can be safely stacked for later collection by your waste contractor. Depending on your disposal partner, finished bales may be eligible for payment.

Arrange delivery of the HSM V-Press 610 automatic baling press to your address and reduce your packaging volume with compact bales. Delivered to your address (DAP) · export price without VAT; export customs clearance at a fixed fee; import VAT and duties are paid by the buyer.

Features of the HSM V-Press 610 eco waste baler

• Digital display – User-friendly membrane keypad with text display, indicating the machine’s current status
• Number of bales per hour: 3–6
• 400 V three-phase electrical connection
• HSM TCS (Torsion Control System) for monitoring the movement of the press ram
• Mechanical bale ejection
• Handwheel door lock – Simple to operate with a counter-rotating thread for swift opening and closing
• Efficient use of space for recycling packaging waste
• Heavy-duty press ram and highly durable press plate guidance
• Special retaining claws improve compaction of material and reduce the frequency of loading
• Pressing cycle begins automatically once the door is closed
• Heavy-duty press ram and highly durable press plate guidance
• To load the press, the upper section of the doors swings open to the right

Technical details for Waste baler HSM V-Press 610 eco

Video of the HSM V-Press 610 eco waste baler

▶
