TONNA bin compactor 240L – 2 tonne pressing force

TONNA 240L bin compactor

The TONNA 240L is a bin compactor for 240-litre waste bins. The bin is placed on the platform, and a hydraulic plate compresses the contents, allowing the bin to hold significantly more waste before emptying is required.

It delivers a pressing force of up to 2 tonnes per cycle, with each cycle lasting 20 seconds.

Operates on 230 V single-phase power, with a 1.5 kW motor and 16 A connection, producing a noise level of 72 dB.

The compactor measures 780 × 780 mm, stands 2360 mm tall, and weighs 235 kg. It is suitable for cardboard, paper, plastics, foam, soft materials and food waste.

TONNA 240L bin compactor: uses and operation

The TONNA 240L bin compactor is ideal for cafeterias, hotels, supermarkets, schools, offices, warehouses and small manufacturing sites where waste is collected in standard 240-litre bins. It integrates into waste handling routines where bins are filled during the day and emptied by staff or waste contractors. The compactor is well suited to areas with limited space and where reducing the frequency of bin emptying is important.

Technical details

How the bin compactor works

• Greater bin capacity. The compactor compresses waste directly inside the bin, so bins need emptying less frequently.
• No bales to move. The compactor operates with your existing 240 litre bin.
• Presses up to 2 tonnes. Hydraulic pressure is applied by a plate designed to fit the bin.
• Standard mains supply. Runs on single-phase 230 V, 16 A, so no three-phase required.
• Fast operation. Each compaction cycle takes just 20 seconds.
• Easy to use. Hold the ON button and move the lever down to compact, up to lift the plate.

Included with your bin compactor

• Compactor for 240 litre waste bins
• Pressing force up to 2 tonnes
• Cycle time: 20 seconds
• Motor: 1.5 kW, single-phase 220–240 V, 16 A
• Controls: ON button and lever (down/up)
• Hydraulic oil capacity: 14 litres (Mobil DTE24 or similar)
• Supplied with four adjustable feet
• Noise level: 72 dB
• Dimensions: 780 × 780 × 2360 mm, weight 235 kg

Operator duties and routine checks: TONNA 240L bin compactor

Before each use, the operator must ensure the bin is intact and free from any forbidden materials. The arms should be adjusted to secure the bin firmly. During compaction, hands must be kept away from moving parts and the operator should monitor for any abnormal sounds or movement.

Always follow the operator manual for safe operation and wear appropriate gloves and safety footwear. Clean the compactor regularly to avoid waste accumulation around the platform and moving components.

How to operate

1. Position the bin on the platform with the lid facing outwards.
2. Adjust the arms to match the width of the bin.
3. Press and hold the green ON button and push the lever down: the pressing plate will compact the waste until it stops automatically.
4. Hold ON and lift the lever up to raise the plate again.
5. Continue filling and pressing until the bin is full; if the press does not operate, press OFF to reset.

Location and maintenance

• Location. Ideally used indoors or under shelter, on a firm, level surface, with good ventilation and lighting; adjust all four feet so the press stands stable.
• Electrical supply. 220–230 V single phase, 16 amp, isolator within 2 metres; if used outdoors, a waterproof IP65 socket with a 30 mA RCD, installed by a qualified electrician.
• Daily. Inspect for signs of wear or oil leaks and keep the compactor clean.
• Monthly. Check oil level, all bolts, guards, cables and hydraulic hoses.
• Annually. Full service including oil change: 14 litres of Mobil DTE24 or equivalent oil.
• Safety. Do not use if cables or hoses are damaged, if there are leaks, or if any parts are loose; never allow anyone beneath the pressing plate.

Selecting and installing the TONNA bin compactor 240L

Ensure the electrical supply meets the requirements and that installation is possible close to a suitable socket or isolator. Plan for safe staff access and easy movement of bins in and out. Avoid placing the compactor in areas exposed to rain or extreme temperatures unless properly sheltered.

Before purchase

The price is shown on this page. Choose a bin compactor based on the bins you use, so please check the following before purchase:

• Your bins. 240 litre waste bins.
• Your waste. Cardboard, paper, plastic, foam, soft materials, food waste; not suitable for cans, metal, wood, glass or pressurised containers.
• Space required. 780 × 780 mm floor area and 2360 mm height clearance.
• Electrical requirements. Single phase 230 V, 16 amp.
• Weight. 235 kg.
• Warranty. 1 year.
